FG Series Frequency / RPM Meter

Large LED Display, easy to read for long distance
Seperate measurement for pulse signal/industrial frequency parameter
Input pulse signal for making use of linespeed, tacho and frequency
Can set coefficient freely, high accuracy
2 decimal point setting for frequency/industrial frequency,
Techo no decimal display

Specification

Power Supply	AC 220V/110±10%, 50/60Hz
Power Consumption	<3VA
Response speed	About 0.5s
Measure accuracy	0.1%F.S
Auxiliary power supply	18V
Working environment	0-50˚C <85%R.H
Dielectric strength	AC 2000V 1min
Insulated inpedance	≥100MΩ
Measure range	Frequency : 0.1-5000Hz, Tacho : 6-9999RPM, Industrial frequency : 0.1-1000Hz
Input voltage	Industrial frequency meter : 60-450VAC Frequency meter : 5-30V pulse volatage
